External rotary switch installation:
You will need to drill a 7mm hole into the panel to place the external rotary switch (note
that the hole needs to be in reach of the 50cm connection cable).
The switch maximum dimensions are:
14mm width
17mm height
18mm length
Installation procedure:
• Remove the plastic key (by just puling it off) and the nut
• Insert the external rotary switch into the cut out and fix it with the nut, then put the
plastic key back up
Speaker installation:
The speaker comes with a 1,5m long connection cable, so you can install it anywhere in
the cockpit within the reach of the cable.
