LX FLARM Eagle - Hardware Connections; RJ 12 FLARM Data Port; Device Ports and Power Input

Main power supply
9-36 V DC
+ red wire
- blue wire
USB port
SMA FLARM RF
Optional*
SMA GPS
RJ 12 FLARM data port
*SMA ADS-B, Diversity
12 V
GND
3,3 V
RX (DATA IN)
GND
TX (DATA OUT)
