• CONNECTION EXAMPLE (mono channel): 2 Ionic-50 + 1 Ionic-12S PRESET 2
CONNECTORS AND CONNECTIONS
ACOUSTIC CENTRE
Speakon
+1/-1
Connect to
power output
Speakon
+1/-1
Speakon
+1/-1
Speakon
+1/-1
Connect to
power input
Cabinet placed
upside down
Connect to
power input
