Ionic Series User Manual
Lynx Pro Audio S.L 12www.lynxproaudio.com
• CONNECTION EXAMPLE (mono channel): 4 Ionic-50 + 1 Ionic-12S PRESET 3
CONNECTORS AND CONNECTIONS
Connect to
power output
Connect to
power input
Connect to
power input
Connect to
power input
Connect to
power input
