CARE & USE/INSTALLATION
|
11
LM24REF/LM24BF/LM24DWR
D
B
C
A
D
B
C
A
SPECIFICATIONS & INSTALLATION
L15ICE/LMWINE/LM15REF
2
1/2
” min. for doors/drawers
* Cocktail Pro should have an open bottom for plumbing and drain access.
1/2” NPT
gas connection
CLEARANCE
33
1/2
”
34”
15”
25”
ICE MACHINE
3”
** 1” square hole must
be located at rear of
grill cutout. 120V GFI
outlet must be located
within 6’ of the 1” hole.
2”Ø or 2” square
holes for manifold
connection
(rear or bottom access)
12” min.
Grill**
Cocktail Pro*
Warming Drawer/
Convenience Center
Utility
Drawer
Side
Burner
Drop In
Cooler
(LDC18)
Access
Doors
A
B
2
1/4
”
3
1/2
”
3
1/4
” min.
2”
3” min.
C
Trash
Center
36
3/8
”
min.
3
1/2
”
8
1/4
”
18
1/4
”
6
1/4
”
18
1/4
”
Trash
Chute
(L18TS)
2
3/
16
''
13 ''
Single
Storage Drawer
3”
min.
Towel
Dispenser
(LTWL)
A
A
A
A
A
B
B
B
B
A
B
B
A
B
A
min.
max.
OUTDOOR REFRIGERATORS
a
e
d
f
c
b
OUTDOOR ICE AND REFRIGERATION
MODEL A B C D
LM15REFL/R 15.00 34.00-35.00 26.00 33.75-34.75
LM24REFL/R 24.00 34.00-35.00 26.00 33.75-34.75
LM24REFCL/CR 24.00 34.00-35.00 26.00 33.75-34.75
LM24BFL/R 24.00 34.00-35.00 26.00 33.75-34.75
LM24DWR 24.25 34.00-35.00 26.00 33.75-34.75
LMWINE 15.00 34.00-35.00 26.00 33.75-34.75
LM15ICE 15.00 34.00-35.00 24.00 33.75-34.75
