LYNX EAVE MOUNTED HEATER PARTS LIST
Item No. Part Number Descripon Qty.
1 14029 Screw, 1/4-20 x 1, HHD, SS 4
2 14030 Screw, 1/4-20 x 1/2, HHD, SS 4
3 31876 Nut, 1/4-20, LKN, ST, W/ESL 4
4 35429 Bracket, Eave Mounng 2
30147 Washer, 3/8, FLT, SS, 7/8 O.D. 8
33511 Screw, 5/16 x 1-1/2, HHD, SS, LAG 8
5 33523 Heat Baffle Lower Shield 2
6 80676 Heat Baffle Assy 2
7 33507 Screw, #8-32 X 3/4, PHP, SS 2
8 33935 Pilot Orifice NG LHEM 1
34032 Pilot Orifice, LP 1
8a 35113 Pilot LHEM 1
8b 35221 Pilo
t tube, LHEM 1
9 33441 Pilot Spacer Bracket 1
11 33417 Mounng Extension Bracket, EaveMount Pao Heater 2
13 32836 Flex Tube, s/s, 3/8" x 9" 1
14 33502 Fing, Brass 90Elbow 3/8 NPT M/F 1
15 33933 Valve, Main 1
16 33504 Cplg, Brass Redr, 1/2 NPT x 1
17 33455 Nipple, Pipe, 3/8 NPT x 5" 1
18 33503 Fing, Brass 90Elbow 3/8 NPT Fem 1
19 33337 Nipple, Pipe, 3/8 NPT x 2 1/2" 1
20 13009 Elbow, Orifice w/o Hood & Pin 1
21 33505 Orifice, #36 Short IR N
G 1
13016 Orifice, 50 LP 1
22 14014 Screw, #8-32 x 3/8, THP, SS 28
23 33930 Baery Holder 1
24 80670 Cover, Side Access 1
25 33984 Grommet, Rubber 1" ID x 1 3/8 OD 1
26 80677 Jack Power Wire Harness LHEM48 1
33993 Sealing Cap, Jack Receptacle 1
27 33983 Hole Plug, Flexible Plasc 1
29 33934 Receiver Module 1
30 33476 Module Holding Strap 1
31 33477 Cover Holding Clip 2
32 33517 Screw, #8-32 x 3/16, PHP, SS 4
33 32532 Grommet, Rubber 5/8" ID x 1 1
/8" OD 1
34 33309 Access Cover 1
35 33311 Igniter Cover 1
36 14018 Screw, #6-32 x 1/4, PHP, SS 15
37 80513 Diffuser Assembly 1
38 33522 Pilot Screen, Heater 1
39 33315 Burner, IR Eave Mount 1
40 33938 Transmier, Touchscreen 1
41 33939 Wall Switch Transmier 1
42 80722 AC Power Adapter w/Jack Plug 1
45 33941 Wiring Harness, Main 1
46 33995 Wire Harness, Stepper Motor 1
47 33475 Module Cover Plate 1
EAVE MOUNTED PATIO HEATER
EXPLODED VIEW PARTS LIST
