SEDONA by LYNX™ READY TO FINISH FIRE PIT ASSEMBLY INSTRUCTIONS
6 SEDONA by LYNX™ Ready to Finish Fire pit Assembly Instrucons
NO. P/N DESCRIPTION QTY.
1 70478 PAN, ASSEMBLY, WLDMT 1
2 35919 COVER, IGNITER, FIREPIT 1
3 35788 COVER, CONTROL 1
4 70482 FACEPLATE, CONTROL, WLDMT 1
5 70479 MANIFOLD WLDMT 1
6 34106 LOGO, SEDONA SMALL 1
7 31773 KNOB, BURNER 1
8 10001 BEZEL, KNOB 1
9 31162 IGNITOR, 2 SPARK 1
10 35925 BATTERY HOLDER, MOD 1
11 35867 BURNER, RTF FIREPIT 1
12 35918 BRKT, FASTENER, BURNER TUBE 2
13 34103 VALVE, MAIN BURNER W/SPRING, RED 1
14 13013 ORIFICE, #41 S 1
15 31795 FTNG, ELBOW 90 DEG. 1/4" TUBE, BRASS 1
16 34038 FTNG, ELB 90, ADP, 3/8-27 F X 7/16-20 M 1
17 13054 ELBOW, 3/8" FLARE TO 1/2" FIP 1
18 32836 FLEX TUBE, S/S, 3/8" X 9" 1
19 35923 ELECTRODE, PRE BURNER, 30" MOD 1
20 31227 WIRE, GROUND, 11" 1
21 35924 WIRE, VALVE TO MODULE, IGNITER 1
22 32816 SCREW, #6-32 X 3/16, PHP, SS 2
23 34035 SCREW, #6-32 X 1/4, THP, SS 1
24 30751 SCREW, #6-32 X 1/2, FHP, SS 2
25 32389 SCREW, #8-32 X 1/4, THP, SS 9
26 33507 SCREW, #8-32 X 3/4, PHP, SS 2
27 33706 SCREW, #10-32 X 3/8, PHP, SS 2
28 14023 NUT, #10-40, SPEED, STEEL 2
29 32768 NUT, #10-32, INSERT, STEEL, ZINC 2
30 31059 WASHER, #10, ESL 1
31 35149 CABLE TIE, HI-TEMP, 4" AR
32 13026 LP REGULATOR W/36" HOSE 1
Fire Pit Parts List
