M-Audio Hammer 88

Parts List
10
+++++ 320010002
Base plating terminal HZ133
RD050587
Printed plate terminal 0.8mm punching piece
MET-0144
1.00000
PCS
++++++ 398010002 SECC 0.8mm
0.00440
KG
++++ 1010114160 Main Board ASSY(AI Part) MK50
1.00000
SET
+++++ 60308001102
CAP ELECT DIP with Tape&Reel
Packing
100uf/16V +20% -20% 5*11mm Pitch:2.5MM
4.00000
PCS
C11 C13 C17 C65
+++++ 60308010201 CAP ELECT DIP
10uf/25V +20%-20% 4*7mm DIP PIN length
3.5+/-0.3MM
5.00000
PCS
C7 C53 C70 C58
+++++ 1010114150 Main board ASSY(SMD Part) MK50
1.00000
SET
++++++ 506040515 PCB Dual layer FR4 1.6mm
MK50_MB_V03 FR4 Pad with HASL Pb-Free
Green oil White Silkscreen 181.5*90*1.6mm
1.00000
PCS
++++++ 608030002 Rectifier Diode SMD IN4001 6.00*3.00mm
1.00500
PCS
D4
++++++ 6060100200 Ferrite Bead SMD BLM18BD102SN1D 1000ohm 0.1A 0603
10.10000
PCS
L1-5 L8-10 L13-14
++++++ 6060100290 Ferrite Bead SMD
BLM18AG601SN1D FERRITE 600R@100MHZ
0603
38.38000
PCS
L7 L12 L16-51
++++++ 6049900040 Common mode inductor
280mA COMMON MODE 0805 ROHS“MURATA
”DLW21HN121SQ2 SMD
1.01000
PCS
L6
++++++ 609010004 Transistor SMD 9014C high frequency low power SMD
6.03000
PCS
D9 D19 D20 D21 D22 D24
++++++ 603010004 CAP CERAMIC SMD 100pf/50V +5% -5% 0603(NP0) SMD
30.30000
PCS
C19-48
++++++ 603010019 CAP CERAMIC SMD 0.1uf/50V +10% -10% 0603 X7R
29.29000
PCS
C1 C2 C4-6 C8 C12 C14 C16
C18 C54-57 C59-64 C66 C67
C71 C72 C74 C77 C78 C90
C91
++++++ 603010038 CAP CERAMIC SMD 20pf/50V +20% -20% 0603 SMD
2.02000
PCS
C9-10
++++++ 603010076 CAP CERAMIC SMD 47pf/50V +5%-5% 0603(NPO) SMD
2.02000
PCS
C79 C80
++++++ 603010188 CAP CERAMIC SMD 510pf/50V ±5% 0603 SMD
5.05000
PCS
C49-52 C69
++++++ 602010013 Resistor SMD 1K ohm(1/16w)+1%-1% 0603
6.06000
PCS
R9-10 R12 R14 R18 R37
++++++ 602010393 Resistor SMD 10K ohm(1/10w)+1%-1% 0603
5.05000
PCS
R3-6 R8
++++++ 602010025 Resistor SMD 1M ohm(1/8w)+5%-5% 0603
3.03000
PCS
R1 R23 R28
++++++ 602010551 Resistor SMD 33 ohm(1/10w) ±1% 0603
1.01000
PCS
R2
++++++ 602030020 Resistor chain SMD 4.7K ohm(1/16w)+5%-5% CRN164
6.03000
PCS
AR1-6
++++++ 602010432 Resistor SMD 27 ohm(1/16w)+1%-1% 0603
2.02000
PCS
R16 R17
++++++ 602010075 Resistor SMD 221 ohm(1/16w)+1%-1% 0603
2.02000
PCS
R11 R13
++++++ 602010604 Resisitor SMD 100 ohm(1/10w)+1%-1% 0603
2.02000
PCS
R15 R22
++++++ 608040002 Schotthy Diode SMD SS24 2A 40V
2.01000
PCS
D2 D5
++++++ 608010004 Switch Diode SMD IN4148 SOP TYPE SMD
2.01000
PCS
D6 D8
++++++ 6010109330 IC SMD
AMS1117-3.3 SOT-223 linear regulater 3.3V 1A
AMS
1.00000
PCS
U3
++++++ 6010109650 IC SMD NUC120RD2BN/LQFP-64 NUVOTON
1.00000
PCS
U2
++++++ 6010100670 IC SMD IMP809TEUR 3.08V 3PIN S0T23 capsulation
1.00000
PCS
U1
++++++ 6010105280 IC SMD BA17805FP 3feet
1.00000
PCS
U4
++++++ 6010107100 IC SMD SN74LVC1G17DCK 5-DCK TI
1.00000
PCS
U5
++++++ 606010012 Ferrite Bead SMD 500mA 600 OHM@100MHz 0805
4.04000
PCS
FB2-3 FB5-6
++++ 60308010201 CAP ELECT DIP
10uf/25V +20%-20% 4*7mm DIP PIN length
3.5+/-0.3MM
1.00000
PCS
C3
++++ 60308006901 CAP ELECT DIP
470uf/25V +20% -20% 10*12mm DIP PIN length
3.5+/-0.3MM
1.00000
PCS
C15
+++ 316080030 Top cover
SECC T=1.2mm Injection black silkscreen
8401C
1.00000
PCS
++++ 31601013501 Top cover
SECC T=1.2mm 1358*131.4*110mm N/A
Modified to increase the screw hole
1.00000
PCS
+++ 628072005
Two sides with Cathode plug
Red/white flat cable
2Pin L=100mm UL2468 26AWG Red/white Two
sides with 2P/2.54 preventing fall off Cathode
plug Lock on the different side
1.00000
PCS
+++ 628072004
Two sides with Cathode plug
Red/white flat cable
11Pin L=160mm UL2468 26AWG Red/white Two
sides with 11P/2.0 preventing fall off Cathode
plug Lock on the different side
1.00000
PCS
+++ 633000156 Double-sided adhesive strips 3M 9448A black 76*3mm
2.00000
PCS
+++ 633000009 Dual side Gummed paper 5mm*50M(NITTO)
0.10000
ROLL
++ 102420082 Wood shell and metal assy MK50
1.00000
SET
+++ 401030187 Wood Shell ASSY PVC 911-4
1.00000
SET
++++ 409030004 Bottom board MDF PVC 1359*283.6*12mm
1.00000
PCS
+++++ 40901009701 Bottom board MDF N/A 1358*283.6*12mm
1.00000
PCS
++++ 406030129 Front board MDF PVC 1359*79*15mm
1.00000
PCS
+++++ 40601006601 Front board MDF N/A 1358*79*15mm
1.00000
PCS
++++ 642030001 PVC Black Small screw thread
0.60200
M
++++ 901040029 PVC-B
0.03100
KG
+++ 901990008 Bolt 6*30
12.00000
PCS
+++ 301010017 screw PA 4*20PA black crisscross PA no harden
4.00000
PCS
++ 102050404 Bottom cabinet ASSY MK50
1.00000
SET
