3 CD10-00013 Diode, LED, Green, Diffused, T1, 3mm, BL-
B2141, TH
6 D6-7,D17-18,D22-23
3 CD10-00014 Diode, LED, Red, Diffused, T1, 3mm, BL-
B4541, TH
2 D4-5
3 CP04-00037 Potentiometer, Linear, 10KB, Single, 30mm
shaft, RK09L1140-F30-C0-B103, Vert
3 R25,R130-131
3 CP06-00022 Potentiometer, Rev-Log, 5KC, Single w/DPDT,
30mm shaft, RK09L1140-F30-C0-C502, Horz
2 R115,R117
3 CR05-62R01 Resistor, Carbon Film, 1/4W, 5%, 62, Thru Hole 4 R97,R139-141
3 CR13-22111 Resistor, Metal Film, 1/4W, 1%, 2.21K, Thru
Hole
5 R96,R121-
122,R129,R134
3 EC04-00010 Connector, Header, 1x10, 2mm, Male,
C10110P1VK0, Vert, Shrd
A1 J9
3 EC04-00040 Connector, Header, 1x6, 2.54mm, Male, Vert,
SHRD
1 J27
3 ES02-00004 Switch, Pushbutton, SPST, Tact, Vert, 6x6mm,
H=5mm, 0.98N, Black
4 S1-4
3 ES02-00011 Switch, Pushbutton, DPDT, PS-22E85L,
Latching, Vert
A1 S8
3 SS8550 SS8550, Q2 Q5 Q11, S0-49 1 Q7
1 9310-61789-00 LBL,UNIT PACKAGING C 1
2 9470-61787-00 DOC CM,PRODUCT LABELING
REQUIREMENTS
D1
1 9310-61797-00 LBL,MULTIPACK CARTON C 0.5
2 9470-61787-00 DOC CM,PRODUCT LABELING
REQUIREMENTS
D1
1 9310-65075-00 LBL,SO-49 START DEMO STICKER A 1
1 9312-65006-00 LBL,FCC/CE,59X41MM,S0-49 A 1
1 9323-65011-00 QUICK SETUP GUIDE,S0-49 JEFIGSC B 1
1 9460-65017-00 BOX,GIFT,CARTON,S0-49 A 1
1 9460-65018-00 BOX,SHIPPING,CARTON,S0-49 A 0.5
1 9460-65051-00 BOX,END CAP,SO-49 SYNTHESIZER, LEFT A 1
1 9460-65052-00 BOX,END CAP,SO-49 SYNTHESIZER, RIGHT A 1
1 9460-65089-00 BOX,END CAP,SO-49
SYNTHESIZER,CENTER
A1
1 9490-65060-00 ASY,MFG DOCS,VENOM US B 1
2 9155-65040-00 1
1 9520-65003-00 ASY,CD,DRIVER,MANUAL,VENOMEDIT
SW,S0-49
C1
1 9940-65001-00 USB CABLE,TYPE A-B,WHITE,6FT/2M A 1
