3 PI12-23530 PROGRAMMED, IC, S0-49, MCU, 256K
FLASH, ARM7
B 1 U13
4 CJ11-00147 IC, MCU, ARM7, 16/32-Bit, 256k Flash, 1
4 IM12-23530 IMAGE, FILE, S0-49, MAIN, MCU, 256K
FLASH, BIN
B1
2 AB22-235
Assy, PCB, S0-49 Top-A Board
A0 1
3 CB22-235 PCB, SO-49 Top-A Board A0 1
3 CD01-00004 Diode, Small Signal, 1N4148, DO-35 9 D16,D19-21,D50-
52,D54,D57
3 CD10-00013 Diode, LED, Green, Diffused, T1, 3mm, BL-
B2141, TH
8 D12-14,D47-
48,D53,D55-56
3 CR05-62R01 Resistor, Carbon Film, 1/4W, 5%, 62, Thru Hole 8 R5-7,R17,R19,R26-28
3 CR13-22111 Resistor, Metal Film, 1/4W, 1%, 2.21K, Thru
Hole
3 R8,R20,R29
3 ES02-00004 Switch, Pushbutton, SPST, Tact, Vert, 6x6mm,
H=5mm, 0.98N, Black
7 S13-16,S25-27
3 ES03-00012 Switch, Rotary, Encoder, 11mm, 15P, 30D,
Detent, Vert
1 S30
3 SS8550 SS8550, Q2 Q5 Q11, S0-49 3 Q2,Q5,Q11
2 AB52-235
Assy, PCB, S0-49 Top-B Board
A0 1
3 CB52-235 PCB, SO-49 Top-B Board A0 1
3 CC03-10031 Capacitor, Ceramic X7R, 25V, 100nF, 10%,
0603
1C1
3 CD01-00004 Diode, Small Signal, 1N4148, DO-35 15 D8-11,D29-31,D36-
39,D43-46
3 CD10-00013 Diode, LED, Green, Diffused, T1, 3mm, BL-
B2141, TH
11 D1-3,D15,D24,D32,D34
35,D40-42
3 CJ12-00006 IC, Logic 3.3V, 74LVC138AD,
Decoder/demultiplexer, 3-to-8, SO-16
1U1
3 CR05-62R01 Resistor, Carbon Film, 1/4W, 5%, 62, Thru Hole 11 R1-3,R9-11,R13-
15,R98,R106
3 CR13-22111 Resistor, Metal Film, 1/4W, 1%, 2.21K, Thru
Hole
8 R21-
24,R4,R12,R16,R138
3 EC04-00040 Connector, Header, 1x6, 2.54mm, Male, Vert,
SHRD
1J1
3 EC04-00048 Connector, Header, 2x13, 2.54mm, Male, Vert,
SHRD
1J8
3 ES02-00004 Switch, Pushbutton, SPST, Tact, Vert, 6x6mm,
H=5mm, 0.98N, Black
7 S5-7,S9-12
3 ES03-00011 Switch, Rotary, Encoder, 11mm, 15P, 30D, No
Detent, Vert
4 S28-29,S31-32
3 SS8050 SS8050, Q9-10 Q14, S0-49 3 Q9-10,Q14
3 SS8550 SS8550, Q2 Q5 Q11, S0-49 4 Q1,Q3-4,Q8
2 AB62-235
Assy, PCB, S0-49 Top-C Board
51
3 CB62-235 PCB, SO-49 Top-C Board A0 1
3 CD01-00004 Diode, Small Signal, 1N4148, DO-35 5 D25-28,D33
