3 CR10-60411 Resistor, Metal Film, 1/16W, 1%, 6.04K, 0603 4 R21,R34,R50,R53
3 CR11-00001 Resistor, Metal Film, 1/8W, 5%, 0, 0805 2 R123,R150
3 CR11-15001 Resistor, Metal Film, 1/10W, 1%, 150, 0805 A 1 R56
3 CR11-22001 Resistor, Metal Film, 1/10W, 1%, 220, 0805 A 1 R153
3 CT11-00002 Transistor, NPN, MMBT3904, 100ma, SOT-23 A 2 Q1,Q3
3 CT12-00002 Transistor, PNP, MMBT3906, 100ma, SOT-23 A 2 Q7,Q9
3 CX01-00002 Crystal, 6.000 MHz, Fundamental, 30pF,
50ppm, HC-49/US
1Y1
3 CX01-00007 Crystal, 11.2896 MHz, 30ppm, fundamental,
Parallel, HC-49/U
1Y2
3 EC01-00003 Connector, PCB, 2.5mm Power Jack, 5A, RJ-
01-C
1 J23
3 EC01-00005 Connector, PCB, 5 pin Midi DIN, 41524, RT
Angle
A 2 J5,J12
3 EC01-00008 Connector, PCB, USB, Type B, 4 pin, RT Angle A 1 J1
3 EC01-00012 Connector, PCB, 6.3mm Stereo Jack, Tip
Switch, with nut/washer, RT ANG
6 J2,J7-J9,J19,J34
3 EC01-00043 Connector, PCB, RCA, Single, Rt Angle, Red,
RJ-2016G(WHITE)
1 J11
3 EC01-00044 Connector, PCB, RCA, Single, Rt Angle, White,
RJ-2016G(RED)
1 J13
3 EC04-00010 Connector, Header, 1x10, 2mm, Male,
C10110P1VK0, Vert, Shrd
A 3 J3,J6,J14
3 EC04-00016 Connector, Header, 1x2, 2.54mm, Male, 22-28-
4020, Vert.
1 J26
3 EC04-00037 Connector, Header, 1x3, 2.54mm, Male, Vert,
SHRD
1 J16
3 EC04-00040 Connector, Header, 1x6, 2.54mm, Male, Vert,
SHRD
1 J15
3 EC04-00043 Connector, Header, 1x6, 2.54mm, Male, 22-28-
4060, Vert
1 J10
3 EC04-00048 Connector, Header, 2x13, 2.54mm, Male, Vert,
SHRD
1J4
3 MM02-00115 MECH,EMI SHIELD,BENT METAL PLATE,S0-
49
3 1 NS1
3 PI12-23510 PROGRAMMED, IC, S0-49, MEMORY,
FLASH, S29GL032M-10TFC
B 1 U18
4 CJ10-00030 IC, Memory, Flash, S29GL032M-10TFC,
32MBit, 100ns, 3V, TSOP-48
1
4 IM12-23510 IMAGE, FILE, S0-49, SAM, FLASH, BIN
(SAM_V0071 + SOUND_V012)
B1
3 PI12-23520 PROGRAMMED, IC, S0-49, MEMORY,
EEPROM, 25LC1024
B 1 U11
4 CJ10-00036 IC, Memory, AT25256A, 256K, 2.7V, Serial
EEPROM, TSSOP-8
A1
4 IM12-23520 IMAGE, FILE, S0-49, DFU BOOTLOADER,
EEPROM, BIN
B1
