M-Audio Venom Service Manual

3 CR02-10021 Resistor, Carbon Film, 1/16W, 5%, 10K, 0603 A 16 R13,R15,R22-R24,R26-
R29,R51-
R52,R62,R94,R104,R1
18-R119
3 CR02-30R01 Resistor, Carbon Film, 1/16W, 5%, 30, 0603 1 R63
3 CR02-56001 Resistor, Carbon Film, 1/16W, 5%, 560, 0603 A 1 R82
3 CR02-5R101 Resistor, Carbon Film, 1/16W, 5%, 5.1 Ohm,
0603
2 R1,R25
3 CR10-00001 Resistor, Metal Film, 1/10W, 5%, 0, 0603 A 4 R64,R86,R88,XR1
3 CR10-10011 Resistor, Metal Film, 1/16W, 1%, 1K, 0603 A 6 R14,R75,R92-
R93,R96,R152
3 CR10-10021 Resistor, Metal Film, 1/16W, 1%, 10K, 0603 A 18 R4,R9-
R12,R18,R31,R42,R59,
R65-R66,R68-R69,R71-
R72,R87,R97,R101
3 CR10-10031 Resistor, Metal Film, 1/16W, 1%, 100K, 0603 A 2 R67,R70
3 CR10-10041 Resistor, Metal Film, 1/16W, 1%, 1M, 0603 A 1 R48
3 CR10-10R01 Resistor, Metal Film, 1/16W, 1%, 10, 0603 A 1 R121
3 CR10-12021 Resistor, Metal Film, 1/16W, 1%, 12K, 0603 A 2 R6,R95
3 CR10-12711 Resistor, Metal Film, 1/16W, 1%, 1.27K, 0603 1 R154
3 CR10-12731 Resistor, Metal Film, 1/16W, 1%, 127K, 0603 1 R624
3 CR10-13731 Resistor, Metal Film, 1/16W, 1%, 137K, 0603 1 R625
3 CR10-15001 RESISTOR, METAL FILM, 1/16W, 1%, 150,
0603
A 1 R81
3 CR10-15021 Resistor, Metal Film, 1/16W, 1%, 15K, 0603 A 2 R622-R623
3 CR10-20001 Resistor, Metal Film, 1/16W, 1%, 200, 0603 A 1 R80
3 CR10-20021 Resistor, Metal Film, 1/16W, 1%, 20K, 0603 A 1 R106
3 CR10-20R01 Resistor, Metal Film, 1/16W, 1%, 20, 0603 7 R60,R73-R74,R78-
R79,R114,R128
3 CR10-22011 Resistor, Metal Film, 1/16W, 1%, 2.2K, 0603 1 R20
3 CR10-24001 Resistor, Metal Film, 1/16W, 1%, 240, 0603 2 R30,R33
3 CR10-24021 Resistor, Metal Film, 1/16W, 1%, 24K, 0603 2 R3,R8
3 CR10-28011 Resistor, Metal Film, 1/16W, 1%, 2.80K, 0603 2 R40-R41
3 CR10-30111 Resistor, Metal Film, 1/16W, 1%, 3.01K, 0603 2 R2,R5
3 CR10-47011 Resistor, Metal Film, 1/16W, 1%, 4.7K, 0603 3 R89,R116-R117
3 CR10-47021 Resistor, Metal Film, 1/16W, 1%, 47K, 0603 A 3 R19,R137,R621
3 CR10-47R01 Resistor, Metal Film, 1/16W, 1%, 47, 0603 A 8 R16-
R17,R43,R76,R105,R1
32-R133,R144
3 CR10-49911 Resistor, Metal Film, 1/16W, 1%, 4.99K, 0603 A 14 R7,R32,R35,R37-
R39,R44-
R47,R49,R54,R57,R15
3 CR10-51011 Resistor, Metal Film, 1/16W, 1%, 5.1K, 0603 2 R145-R146
3 CR10-51101 Resistor, Metal Film, 1/16W, 1%, 511, 0603 A 1 R90
3 CR10-54901 Resistor, Metal Film, 1/16W, 1%, 549, 0603 A 1 R58

M-Audio Venom Specifications

General

Synthesis Type	Virtual Analog
Polyphony	12 voices
Oscillators	3 per voice
Arpeggiator	Yes
Headphone Output	1 x 1/4" TRS
Effects	Distortion, delay, reverb, chorus, phaser
Keyboard	49 keys
MIDI	In, Out, USB
Audio Outputs	2
