47LV
P. 14 / 18EM-9502-B Rev.3
PARAMETER INDICATORS FUNCTION
DEFAULT
VALUE
DISPLAY
...
...
...
HH setpoint*
HH deadband (hysteresis)
HH ON delay time
HH: ON delay time (seconds)
HH: Deadband (hysteresis) value
HH: Setpoint value
HH trip action
HH: Hi trip
HH: Lo trip
HH coil at alarm
HH: Coil energized at alarm
HH: Coil de-energized at alarm
* ‘Default Value’ shows values for input code in order from 1 through 6.
Note 1: Alarm Setting Mode is locked with no-alarm-output type.
Alarm points depend upon the model suffix code. LL and HH setpoints are usable only for quad alarm type.
Note 2: LED status: = ON, = Blinking
Note 3: Specify setpoint and deadband in the scaled range values. Alarm is disabled when ‘ – – – – ’ is specified for the setpoint.
Note 4: All alarm setpoints are disabled (reset to ‘ – – – – ’ status) when the input type has been changed. Re-setting is required.
Note 5: Alarm is set with the display value.
Note 6: Decimal point is not indicated when setting deadband values.
Note 7: Alarm indicators are shown at ‘S.ERR’ error (input signal out of the usable range) for the product version 2.00 or higher.
Note 8: During setting mode, status indicators and also alarm indicatorsturn on according to the alarm status when changing mode.
Main display flashing
at alarm
Flashing in 1.0 sec. intervals
No flashing
Flashing in 0.1 sec. intervals
Flashing in 0.2 sec. intervals
Flashing in 0.5 sec. intervals
2.00
2.00
2.00
HH Fnc
HH Fnc
D/PHH Fnc
HHH Fnc
D/PHH Fnc
HHP Fnc
HH Fnc
HH Fnc
Fnc
2.00
2.00
2.00
