2.2 Interface options
 Front-side connectors
 1 – 2 x USB 1.1 host connector for USB device socket
 2 – Micro-SD card socket
 3 - Antenna SMA connector
 4 – GSM network response LEDs (colours: green, red; signal: GPRS/3G)
 5 – Interface connector socket (RS485, MBUS (for ex. calorimeter))
 6 – case fixing screw
 7 – hard-wire mounting (C-slide)
1
6
2
2
4
5
6
3
7
