M3 SMART - Device Overview and Components; Scanner Types (1 D and 2 D); Physical Device Layout

02
FEATURES
Barcode Scan Window
Scanner Button
Charging LED
Scanner LED
POGO Pin
Keypad
Battery
Reset Button
Volume Keys
Camera Button
Scanner Button
LCD Touch Screen
Battery Lock
Charging &
USB/serial Port
DEVICE
< 1D Scanner > < 2D Imager >
