Specification
Weight approx. approx. 1,3 kg / 2,9 pounds
Dimensions: 210mm x 45mm x 185mm / 8,3 x 1,8 x 7,3 inch
2 DMX – OUT (XLR 5 pin) on the rear side. Each DMX OUT can be individually configured as DMX IN.
Ethernet RJ 45 network connector
USB Port connector on the front side. For update via USB-stick only. Do not connect any peripheral
device (mouse, keyboard or similar)
2“ TFT color monitor
2x DMX Out (MA 2Port Node)
Up to 1 024 parameters (MA 2Port Node onPC 1k)
Up to 2 048 parameters (MA 2Port Node onPC 2k)
