45
Minimum height
2.20 m
Basket
protector
Angle brace
Base
Unpacking your washing machine
Figure D
Figure E
Figure F
Connections
Draining hose
Requirements
Water pressure: To ensure proper filling
pressure, there must be a height of at least
2,20 m between the base of the water tank
and the water entry (fig. 1). In the event of
having a cistern or reservoir, it is necessary
to have a pump that ensures good pressure
(at least 20 psi/138 kPa). The less bends or
elbows the water supply piping has, the
better the filling pressure.
Tip: If the filling time is greater than 6-8 minutes at minimum water level, check that the
filters are not blocked and that there are no pressure problems during installation.
Proper washing machine installation is
simple, you can do it.
Be sure to remove all package accessories
from both the top and bottom parts of your
washing machine.
The draining hose is located inside your washing machine; to extract it follow these steps:
The hose is located on the
back side of your washing
machine (lower back side),
firmly grip the part of the
hose (fig. D) from the
protruding end and pull
the upper part outwards
(fig. E) until extracting it
completely (fig. F).
