PRINTED : JAN’2015 REF NO. SM7715010-01-11
1-2) Product
Model ITV085ICER ITV095ICER ITV110ICER ITV120ICER
Classification 2 Doors No Frost
Temperature Control Electronic control
Defrost System Automatic
Drain System Automatic (Heat by transfer from the Condenser)
Evaporator Fined Evaporator
Condenser Pipe Condenser
Insulation
Cabinet Rigid Polyurethane Foam ( Cyclopentane )
Freezer Door Rigid Polyurethane Foam ( Cyclopentane )
Refrigerator Door Rigid Polyurethane Foam ( Cyclopentane )
Refrigerant R-600A R-600A R-600A R-600A
Refrigerant Charge (g.) 46 46 64 64
Overall Dimension (WxDxH (mm.)) 545 x 645 x 1573.5 545 x645x1678.5 595x 677 x 1650.5 595 x677x1754.5
Packing Dimension (WxDxH (mm.)) 580 x 726 x 1674.5 580x726x1779.5 630x755x1751.5 630x755x1846.5
Net Weight (kg.) 50 52 55 59
Gross Weight (kg.) 56 58 61 65
1-3) Electrical Parts
Compressor Model VNX113Y
Electrical data Input: 220-240V 50-60Hz
Connection Connector CN6 on main PCB
Between circuit 1(BL) – 3 (BR)
Resistance value
V-U : 7.3
V-W : 7.3
U-W : 7.3
Inverter control box Model MZ-259-02R220C
Electrical data Input : 220-240 VAC 50Hz 1.6A 1PH
Output: 70-200V DC 40-150Hz 1.5A 3PH
Connection Connector CN8 on main PCB <signal>
Between circuit 1(Y) – 4 (W)
Defrost heater Model -
Electrical data
130W 220V R: 372.3Ω (HRF-315FI, 340FI)
120W 220V R: 403.3Ω (HRF-245FI, 265FI)
Connection Connector CN4 on PCB
Between circuit 1(R) – 5 (B)
