Page 3
PRINTED : JAN’2015 REF NO. SM7715010-01-11
1-3) Electrical Parts
Freezer Fan motor Model DG8-013U12M
Electrical data 9 V DC 0.6W
Connection Connector CN9 on PCB
Between circuit 1(Y) – 2 (BL)
Thermal fuse Model SF76E
Electrical data 10A 250V
cut-off temperature 77 C
Connection Series connection with Defrosting heater
Defrost sensor Model
‐ <NTCThermister>
Electrical data
Resistance value
0℃：6.0KΩ
25℃：2.18KΩ
Connection Connector CN7 on PCB
Between circuit 3(G) – 5 (B)
R-Sensor Model
‐ <NTCThermister>
Electrical data
Resistance value
0℃：6.0KΩ
25℃：2.18KΩ
Connection Connector CN7 on PCB
Between circuit 4(B) – 6 (W)
Ambient Sensor Model
‐ <NTCThermister>
Electrical data
Resistance value
0℃：6.0KΩ
25℃：2.18KΩ
Connection Connector CN11 on PCB
Between circuit 1(W) – 3 (W)
R-Volume Model -
Electrical data
Volume resistance 10 KΩ at Center position
Connection Connector CN7 on PCB
Between circuit 1(Y) – 2 (W)
R-LED PCB Model -
Electrical data 12V DC
Connection Connector CN5 on PCB
Between circuit 1(P) – 4 (GR)
Door switch Model D3D-211
Electrical data 250V AC 0.5A T55
Connection Connector CN7 on PCB Between circuit 7(P) –8(W)
