16
Service, maintenance, and transport
Warning! Do not remove the cover of the reader� Injury to eyes from UV
light can occur� All internal service and maintenance work must be done by a
technician approved by Mabtech� Contact Mabtech for more information�
Caution! Only use shielded signal cables that are shorter than 3 m to
comply with applicable EMC requirements� If the USB cable is longer than 2
m, the connection between the reader and the computer can stop working�
Caution! Use only the parts specied below. Using other parts will void the
warranty�
Return the equipment in the same box that it arrived in for repair/service/transport�
Environmental conditions for transport and storage should be according to IEC 60068-2
and IEC 60721- 3:
• Public transportation: -40 to +70ºC
• Storage locations: -25 to +55ºC
Only the following parts can be replaced by the user:
Part Description
Power cable • 240 V/10 A (international) or 100 V/15 A (North America)
• IEC 60320-1 C13 connector
Ethernet cable • Shielded Ethernet cable (SFTP or STP)
• Cat� 5e or 6A
• RJ45 male – RJ45 male
• ≤ 3 m
USB cable • Shielded USB cable
• Type A 3�0 male - type B 3�0 male
• ≤ 2m
Fuses x 2 • Cartridge fuses SP 5×20
• 250V 4A
• IEC 60127-2
• Quick-Acting F, H (H = High Breaking Capacity (Ceramic Tube))
Note: All components in Mabtech IRIS™ are compliant with RoHS(Restriction of
Hazardous Substances Directive, 2011/65/EU)�
