GUN SAFETY DEVICE
Whenever you use the high pressure washer, we suggest you grip the in the right position, with
one hand on the handle and the other on the lance, When you stop the machine it is necessary to
use the safety lock placed on the gun in order to avoid accidental.
CLEANING PIN INSTRUCTION
• Using included tip cleaner, or an unfolded paper clip, insert wire into the nozzle hole
and move back and forth until debris is dislodged.
• Remove additional debris by back-flushing water through the nozzle. To
do this, place end of a garden hose ( with water running ) to the end of nozzle for
30-60 seconds.
MAJOR TECHNICAL DATA
ITEM
HCLEAN150(APW-VSA-150P)
Working pressure
15MPa(150 bar)
Allowable pressure
22.5MPa(225 bar)
Working flow rate
6.8 l/min
Max. flow rate
8.5 l/min
Max. pressure water supply
0.4MPa(4bar)
Motor Capacity
3.0 kw
Power Supply Voltage
230
V~50Hz
Max. Water Temperature
50 ℃
Weight
24 kg
Dimensions(CM)
93x 40.5 x37.5
