Getting
started...
You will need
(items not supplied)
Suitable personal protective equipment
Suitable crosshead screwdriver
(items supplied)
Guard (17)
Trimmer head (18)
Battery pack (19)
Charger (20) and its manual
Cutter blade (3-Teeth) (21)
Harness (22)
Multi tool (23)
Spindle lock rod (24)
Hex key (4mm) (25)
NOTE:
The accessories required depend on the intended application.
Ask your dealer for advice.
Setup
WARNING!
The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to battery pack (19) before it is completely
assembled!
NOTE:
Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid loss.
Pole assemble
1. Loosen the lock knob (15) counter-clockwise (Fig. 1, step 1).
2.Removetheblackprotectivesleeve(16a)rstly,thenalignthelowerpole(16)
with the locking sleeve (15b) and insert it (Fig. 1, step 2). Make sure the pin
(15a) matches the bore (15c).
3. Make sure the pin (15a) snaps in place (Fig. 2).
4. Secure the connections with the lock knob (15) (Fig. 1, step 3).
