9.4 Bluetooth Class 1
Wireless connection
ET650 to PC/Laptop
Minimum range
Workshop environment in the open
space
30 meters
If the vehicle door or window is
open and the engine is still running
in the vehicle interior
10 meters
9.5 RED (Radio Equipment Directive)
Wireless link Frequency band Maximum radiated
transmitter power
output
Bluetooth 2,4 GHz 19,9 dBm
WLAN 2,4 GHz 19,9 dBm
20 | ET750 | Technical Dataen
9. Technical Data
9.1 Temperature and humidity
Designation Value/range
Operating temperature 5 °C – 40 °C
41 °F – 104 °F
Storage temperature -20 °C – 60 °C
-4 °F – 140 °F
Relative operating humidity 20 – 80 % non-
condensing
9.2 ET750
Characteristic Value/range
Display 10“ TFT, WXGA
(1024 x 600 Pixel)
Operating system Windows 10 IoT (64-bit)
Main-memory capacity 4 GB DDR3 RAM
Interfaces USB 3.0 (2x)
LAN 10/100 Mbit
VGA, Audio
Hard disk 256 GB SSD
WLAN WLAN 802.11 b/g/n
Bluetooth Bluetooth 2.1
Class 1
Storage battery (Li-ion) 7,26 V/ 5200 mAh
Dimensions (H x W x D) 249 x 329 x 53 mm
9.8 x 12.9 x 2.1 inch
Weight with storage battery,
without power supply unit
2,1 kg
4.6 lb
Degree of protection IP 20
9.3 ET650
Characteristic Value/range
Operating voltage 7 VDC — 30 VDC
Power consumption via vehicle battery or
power supply unit
approx. 6 Watt
Dimensions (H x W x D) 120 x 170 x 40 mm
4.7 x 6.7 x 1.6 inch
Weight (without accessories) 325g
0,72 lb
9.6 Communication protocol ET650
The following interfaces and their associated protocols
are supported for control unit diagnosis in compliance
with ISO 15031:
R ISO 9141-2 (communication lines K and L)
R SAE J1850VPW and SAE J1850PWM
(communication lines BUS+ and BUS-)
R CAN ISO 11898 ISO 15765-4 (OBD)
(communication lines CAN-H and CAN-L)
R CAN Single Wire
R CAN Low Speed
9.7 Power supply unit
Characteristic Value/range
Input voltage (AC) 100 - 240 VAC
Frequency 50 – 60 Hz
Input current 1,6 A
Output voltage (DC) 12 V
Max. output current 5.0 A
