PACKAGE CONTENTS LIST
Your Riello 40 burner should include the following parts. Please check to make sure all parts are present before begin-
ning the installation.
SERIAL NUMBER IDENTIFICATION
Your Riello burner may have been manufactured in more than one location and therefore there are two possible serial
number identification.
The Riello 9 character serial number, example,
06 01 12345, is identified as follows:
06 = Last two digits of the year of manufacture;
01 = Week of manufacture;
12345 = Increment of 1 for each burner produced – specific
to product code – reset to zero each January 1
st
.
The Riello 15 character serial number, example,
06 A 8511111 00025, is identified as follows:
06 = Last two digits of the year of manu-
facture;
A = BI-week of manufacture;
8511111 = Burner product code;
00025 = Increment of 1 f or each burner pro-
duced – specific to product code –
reset to zero each January 1
st
.
Quantity Description Code
1 Burner chassis with cover 3726512
1 Universal mounting flange + mounting gasket 2567395
1 Parts bag 2566283
1 Parts bag 2567338
1 Installation manual 2902453
1 By-pass plug
1
Separate carton - OEM burners shipped with combustion head mounted
Air Tube/Drawer Assembly
Parts bag 2566283 Parts bag 2567338
Quantity Description
Quantity Description
1
1
1
1
2
2
2
Female 1/4” NPT adapter
Male 3/8” NPT adapter
Oil pump connector (supply)
Oil pump connector (return)
Mounting flange bolts (short)
Nuts
Chrome nuts
2
2
2
2
Semi-flange bolts (long)
Semi-flange
Cover screws
Nuts
(06) (01) (12345)
Year of
manufacture
Week of
manufacture
Increment
(06) (A) (8511111) (00025)
Year of
manufacture
Burner
product code
Increment
BI-week of
manufacture
