MAIN COMPONENTS
1. Power unit
2. Drive tube
3. Drive tube terminal
4. Cutting line head
5. Cutting device guard
6. Front handgrip
7. Rear handgrip
8. Spark plug
10. Identification plate
CONTROLS AND REFUELLING
21. Engine stop switch
22. Throttle trigger
23. Throttle trigger lockout
24. Starter
25. Choke
26. Primer
31. Fuel tank cap
2 IDENTIFICATION OF MAIN COMPONENTS
1. IDENTIFICATION OF MAIN COMPONENTS
IDENTIFICATION PLATE
10.1) Conformity marking in accor-
dance with Directive 2006/42/EC
10.2) Name and address of the manufacturer
10.3) Acoustic output level LWA in accordance
with directive 2000/14/EC
10.4) Machine model
10.5) Serial number
10.6) Year of manufacture
10.7) Article Code
10.8) Emission number
10.1 10.2
10.6
10.3
10.5
10.4
10.710.8
3
4
5
2
6
7
10
21
23
22
18
25
26
31
24
