MACHINIST B75-PRO-U5 User Manual

Any problem, please feel free to contact us.
—
1
—
Specifications
B75-PRO-U5
Processor
Supports Intel Core i3/i5/i7 2th or 3th generation, Xeon E3 v2, Pentium and
Celeron series processors
Southbridge
B75 Chipset
RAM
Technology
Dual channel DDR3
Maximum
Capacity
16GB (8GB*2)
Memory Slot
2 * DDR3
Rear I/O
PS/2
Green: mouse. Purple: keyboard
Display Interface
1 * HDMI, 1 * VGA
USB
2 * USB 2.0, 2 * USB 3.0
Ethernet
1 * Gigabit LAN Card
AUDIO
1
*
RJ45/6 x Audio Jacks
Internal
connector
CFAN
1 * 4PIN
SFAN
2 * 3PIN
Power Connector
24 + 4PIN Power Socket
USB2.0(front)
1
USB3.0(front)
1
M.2(SATA)
1
SATA Interface
1 * SATA3.0, 3 * SATA2.0
JAUDIO1(front)
1
JCOM (front)
1
JLPC
1
PCIe
1 * PCIe x16; 1 * PCIe x1
PCI
1
Environment
Temperature
Range
Working Environment
Storage Environment
Temperature：0～50°C
Humidity：5%~95%
Temperature: -20~70°C
Humidity: 5%~95%
Physical Size
Size
240mm*170mm
