MACHINIST H81M-PRO-S1 User Manual

Any problem, please feel free to contact us.
—
1
—
Specifications
H81M PRO
Processor
Supports Intel 4th generation Core i3/i5/i7, Xeon E3/V3 series, Celeron G
series and Pentium G series processors.
Southbridge
H81 Chipset
RAM
Technology
Dual channel DDR3
Maximum
Capacity
32GB (16GB*2)
Memory Slot
2 * DDR3
Rear I/O
PS/2
Green: mouse. Purple: keyboard
Display Interface
1 * HDMI, 1 * VGA
USB
2 * USB 2.0；2 * USB3.0
Ethernet
1 * Gigabit LAN
AUDIO
1 (Mic-in, Line-out、Line-in)
Internal
connector
CFAN
1 * 4PIN
SFAN
1 * 3PIN
ATXPWR Interface
1 * 8PIN Power Socket；1 * 24PIN Power Socket
USB2.0(front)
1
USB3.0(front)
1
M.2(SATA)
1
SATA Interface
4 (2 * SATA3.0; 2 * SATA2.0 )
JAUDIO(front)
1
JCOM (front)
1
JCMOS Port
1
PCIe
1 * PCIe x16; 1 * PCIe x1
JPEAK1
1
Environment
Temperature
Range
Working Environment
Storage Environment
Temperature：0～50°C
Humidity：5%~95%
Temperature: -20~70°C
Humidity: 5%~95%
Physical Size
Size
220mm*170mm

MACHINIST H81M-PRO-S1 Specifications

General

Brand	MACHINIST
Model	H81M-PRO-S1
Category	Motherboard
Language	English
