Macintosh SE - Page 117

Adjustments Yoke - 5
4 Switch off and unplug the
computer.
5 Discharge the CRT.
6 Hold the plastic collar
in position and carefully
tighten the yoke clamp
screw so that the collar
cannot slip. Do not
overtighten the screw.
7 Replace the cover and
switch on the computer.
Make sure the top and
bottom edges of the
picture are parallel with
the top and bottom of the
bezel.
Yoke Collar
Yoke Clamp
Screw
