Macintosh SE - Page 63

Take Apart Fan Assembly - 35
3 Remove the four
mounting screws and
lockwashers and remove
the fan assembly from
the analog board.
Note: On earlier
versions of the analog
board you may have to
desolder the fan itself
from the analog board at
the solder points shown.
(Solder Side)
Fan Solder Points
