Take Apart Fan Assembly - 37
Replacement Note:
Some
replacement fans have a
black wire and a yellow wire
that must be soldered to the
back side of the analog board.
Insert these wires through
the arrow clip hole in the
board and solder them to the
points shown.
Black Wire
Yellow Wire
(Solder Side)
