Mack LRBE - Access to the Occupants

Identiicationnumber
Versionnumber Pagenumber
800077265
06/2021
5
If the charging plug cannot be pulled out : retract the pin manually
Turn off the chassis switch (up) to intiate the high voltage
disconnection process.
Rotate the lever (1) and remove the charging plug (2).
1
2
ON
OFF
1
2
4.Accesstotheoccupants
1
Opening doors from the outside
Insert the key (1) in door lock and turn in anticlockwise direction to
unlock the right-hand side door.
1
To open the door, grasp the handle (2) and pull out while exerting
some force on the door.
3
Opening doors from the inside
To open the door, pull the handle (1) while exerting some
force on the door.
1
Seat adjustment
To raise the seat, pull the air valve button (1) upwards.
1
To lower the seat, push the air valve button (1) downwards.
2
1
Pull the fore and aft adjustment lever (2) and slide the seat to
the desired position.
3
2
1
2
Turn the key (1) in clockwise direction to unlock the left-hand side
door.
2
1
2
