HD1521
HIGH-DEFINITION POWERED
LOUDSPEAKER
Two per side Two on the rear
Three each on the top and bottom
12 Fly Points
FLY POINTS
Input
XLR
Loop
Out
XLR
HF
LF
Amp
Amp
Digital to
Analog
Converter
Digital to
Analog
Converter
Analog to
Digital
Converter
Signal /
Limit LED
HD
Loudspeaker
Processing
Limiter
Limiter
Mute
Level
Control
HD
Loudspeaker
Processing
3-Band Contour EQ
80 100-8K 12K
LO MID HI
Thermal
Monitoring
Flown V e rtically
Top Fly Points
Side Fly Points
Rear Fly Points
(adjusts angle)
Lower Rear
Fly Point
(adjusts angle)
Flown Horizontally
