14
Frequency (Hz)
Attenuation (dB)
20 100 1000 10000 20000
–30
–20
–10
0
10
0 deg
10 deg
20 deg
30 deg
40 deg
SA1232 Horizontal Off-Axis Frequency Response
Frequency (Hz)
Attenuation (dB)
20 100 1000 10000 20000
–30
–20
–10
0
10
0 deg
–10 deg
–20 deg
–30 deg
–40 deg
SA1232 Vertical Off-Axis Frequency Response (Down)
Frequency (Hz)
Attenuation (dB)
20 100 1000 10000 20000
–30
–20
–10
0
10
0 deg
10 deg
20 deg
30 deg
40 deg
SA1232 Vertical Off-Axis Frequency Response (Up)
