Mackie SRM450v3 User Manual

Owner’s Manual
3
Owner’s Manual
Contents Features
Part No. SW1051 Rev. A 03/14
©2014 LOUD Technologies Inc. All Rights Reserved.
• 1000Wsystempowerpairedwithcustom 
  transducersdelivergig-levelvolumeswith
  roomtospare
 • 10"high-outputLFdriver[SRM350v3]
 • 12"high-outputLFdriver[SRM450v3]
 • 1.4"titaniumdomecompressiondriver
• High-DenitionAudioProcessingforprofessional
  soundwithunmatchedclarity
 • Patentedacousticcorrectiondevelopedwith
   touringgeniusesatEAW
®
 • Precision2-waycrossover
 • Drivertimealignmentandphasecorrection
• Quickone-buttonSpeakerModeselection
  forapplication-specicvoicing(PA,DJ,Monitor
  andSoloist)
• Effortlesslyeliminatenastyfeedbackwith
  one-buttonautomaticFeedbackDestroyer
• Integrated2-channelmixerfeaturingdual 
  Wide-Z
™
inputs
 • Handlesanythingfrommicstoguitarsto 
   mixerswithasingletwistofthegainknob
 • IncludesstereoRCAinputsforeasyconnection
   tomusicsource
 • Perfectforthesinger/songwriter,
   pluginandleavethemixerathome
• SmartProtect
™
DSPkicksintoprotect
  yourinvestmentwhenthingsgetpushed
  alittletoohard
• Monitor-specicangleandvoicingmode 
  perfectforcuttingthroughonstage
• Flyableforpermanentinstall
• Provenhighly-durable,portabledesign
 • 23.0lb/10.4kg[SRM350v3]
 • 37.0lb/16.8kg[SRM450v3]
Like us
Follow us
Watch our dang videos
Important Safety Instructions .................................. 2
Contents ................................................................. 3
Features ................................................................. 3
Introduction ............................................................ 4
How To Use This Manual ......................................... 4
Getting Started ....................................................... 4
Things To Remember ................................................ 4
Hookup Diagrams .................................................... 5
SRMv3 Loudspeaker: Rear Panel Features ................ 9
1. Power Connection ......................................... 9
2. Power Switch ............................................... 9
3. XLR and 1/4" Combo Inputs .......................... 9
4. Gain Knobs ................................................. 10
5. RCA Inputs [Channel 2 Only] ....................... 10
6. Thru Output ................................................ 10
7. Ch 1/Mix Switch [Thru Output] ................... 11
8. Speaker Mode ............................................ 11
9. Feedback desTROYer ................................... 11
10. Main LED Switch / Limit LED ..................... 11
11. Breakfast Mode ........................................ 11
Smart Protect ....................................................... 12
Limiting .......................................................... 12
Overexcursion Protection ................................ 12
Thermal Protection .......................................... 12
AC Power ............................................................. 12
Care and Maintenance ........................................... 12
Placement ............................................................. 13
Room Acoustics ............................................... 14
Rigging ............................................................... 15
Rigging Design Practices .................................. 15
Rigging Hardware and Accessories ................... 15
Rigging Notes ................................................. 15
SRMv3 Inserts & Fly Points ............................. 15
Appendix A: Service Information ............................ 16
Appendix B: Connections ....................................... 17
Appendix C: Technical Information .......................... 18
SRMv3 Loudspeaker Dimensions ...................... 20
SRMv3 Loudspeaker Frequency Responses ....... 21
SRMv3 Loudspeaker Block Diagram ................. 22
Limited Warranty .................................................. 23

Mackie SRM450v3 Specifications

General

Woofer	Yes
Tweeter	-
Magnet type	Ferrite
Speaker type	2-way
Speaker placement	Tabletop/bookshelf
Audio output channels	2.0 channels
Number of woofer drivers	1
Woofer diameter (imperial)	10 \
Product color	Black
Recommended usage	Universal
Impedance	8 Ω
Sensitivity	128 dB
Frequency range	47 - 20000 Hz
RMS rated power	500 W
Crossover frequency	3000 Hz
Peak Music Power Output (PMPO)	1000 W
Connectivity technology	Wired
Current	10 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	160 W
Operating temperature (T-T)	0 - 40 °C
Package depth	432 mm
Package height	737 mm
Package weight	19500 g

Weight and Dimensions

Depth	376 mm
Width	406 mm
Height	663 mm
Weight	16800 g
