Wetted Parts MX06P MX09P - MX12P MX19P - MX50P MX75P - MX100P
METER BODY SS 316 SS 316 SS 316
*
METER CAP SS 316 SS 316 SS 316
*
ROTORS SS 316 SS 316
SS 316/PEEK ** *
HIGH VISCOSITY ROTORS - SS 316 SS 316
*
ROTOR SHAFTS SS 316 SS 316 SS 316
*
ROTOR BUSHES CARBON CARBON CARBON
*
O-RINGS FEP FEP
*
FEP
Wetted Parts MX06S MX09S - MX12S MX19S - MX25S MX40S - MX50S MX75S - MX100S
METER BODY AL AL AL AL AL
METER CAP AL AL AL AL AL
ROTORS SS 316 SS 316
SS 316/PEEK ** AL/PEEK **
AL
HIGH VISCOSITY ROTORS - SS 316 SS 316 AL AL
ROTOR SHAFTS SS 316 SS 316 SS 316 SS 316 SS 316
ROTOR BUSHES CARBON CARBON CARBON CARBON CARBON
O-RINGS FEP FEP FEP FEP FEP
WETTED PARTS
FEP - PTFE Encapsulated
SS 316 - Stainless Steel 316
AL - Aluminium Alloy
PEEK - Polyether ether ketone
* Currently Unavailable
** SS 316 and AL rotors are assembled with carbon bushes. PEEK rotors do not have carbon bushes.
