Maco MULTI-MATIC - Setting the Closing Element, Bullet Catch, and Sash Lifter; Gasket Compression on Cam; Sash Lifter Adjustment; Door Catch;Bullet Catch Roll Setting

- 14 -
15
-0,55 / +0,55
-0,75 / +0,75
9
-3 / +3
15
-3 / +3
15
-0,5 / +0,5
-2 / +2
4
MULTI-MATIC MULTI-TREND
Setting the closing element, the bullet
catch and the sash lier
› Setting the gasket compression on the cam
› Setting the sash lifter
› Setting the door catch and/or the bullet catch roll
i.S. Security roller cam
Locking cam
