ELETTROVALVOLE NORMALMENTE CHIUSE AUTOMATICHE TIPO EVP/NC - EVPC/NC
EVP/NC - EVPC/NC AUTOMATIC NORMALLY CLOSED SOLENOID VALVES
ELECTROVANNES NORMALEMENT FERMEES AUTOMATIQUES DE TYPE EVP/NC - EVPC/NC
ELECTROVÁLVULAS NORMALMENTE CERRADAS AUTOMÁTICAS TIPO EVP/NC - EVPC/NC
6
2011 Technical Manual
Chapter 2 (Rev. 0)
Manuel Technique 2011
Chapitre 2 (Rev. 0)
Manual Técnico 2011
Capítulo 2 (Rev. 0)
EVP/NC
EVPC/NC
© 2011 MADAS s.r.l.
Capitolo - Chapter
Chapìtre - Capitulo
2
Foto
Fotos
Attacchi
Connections
Fixations
Conexiones
Voltaggio
Voltage
Voltage
Voltaje
Attacchi Filettati - Threaded Connections
Fixations fi letees - Conexiones roscadas
Attacchi Flangiati - Flanged Connections
Fixations Bridees - Conexiones de Brida
P.max 360 mbar P.max 360 mbar
Codice - Code
Code - Código
Codice - Code
Code - Código
EVP/NC
DN 32
12 Vdc EVP05 001 EVP32 001
24 Vdc EVP05 005 EVP32 005
24 V/50 Hz EVP05 003 EVP32 003
110 V/50 Hz EVP05 002 EVP32 002
230 V/50-60 Hz EVP05 008 EVP32 008
EVP/NC
DN 40
12 Vdc EVP06 001 EVP40 001
24 Vdc EVP06 005 EVP40 005
24 V/50 Hz EVP06 003 EVP40 003
110 V/50 Hz EVP06 002 EVP40 002
230 V/50-60 Hz EVP06 008 EVP40 008
EVP/NC
DN 50
12 Vdc EVP07 001 EVP50 001
24 Vdc EVP07 005 EVP50 005
24 V/50 Hz EVP07 003 EVP50 003
110 V/50 Hz EVP07 002 EVP50 002
230 V/50-60 Hz EVP07 008 EVP50 008
EVP/NC
DN 65
24 Vdc - EVP08 005
24 V/50 Hz - EVP08 003
110 V/50 Hz - EVP08 002
230 V/50-60 Hz - EVP08 008
EVP/NC
DN 80
24 Vdc - EVP09 005
24 V/50 Hz - EVP09 003
110 V/50 Hz - EVP09 002
230 V/50-60 Hz - EVP09 008
EVP/NC
DN 100
24 Vdc - EVP10 005
24 V/50 Hz - EVP10 003
110 V/50 Hz - EVP10 002
230 V/50-60 Hz - EVP10 008
EVP/NC
DN 125
24 Vdc - EVP11 005
24 V/50 Hz - EVP11 003
110 V/50 Hz - EVP11 002
230 V/50-60 Hz - EVP11 008
EVP/NC
DN 150
24 Vdc - EVP12 005
24 V/50 Hz - EVP12 003
110 V/50 Hz - EVP12 002
230 V/50-60 Hz - EVP12 008
EVP/NC
DN 200
24 Vdc - EVP13 005
24 V/50 Hz - EVP13 003
110 V/50 Hz - EVP13 002
230 V/50-60 Hz - EVP13 008
con regolatore di portata = EVPF....
with fl ow regulator = EVPF....
avec régulateur de portée = EVPF....
con regulador de caudal = EVPF....
