9
– Attach the Arrow
WAN 2
module (2) to the
relevant housing.
2
– Lower the module and oset it.
– Attach the eyelet (3) to the catch (4) and
realign the module.
3
4
l
WARNING!
Do not apply pressure to force
the eyelet in.
– Fasten the module using the screw (5) and
apply the anti-fraud seal (6).
5
6
