MADDALENA ElecTo Bulk - Display Menus and Data; Primary Menu Displays; Secondary Menu Data; Meter Seals and Servicing

3
Primary menu
Secondary menu
Faults
Volume flowed: m
3
Pipe pressure (kPa, version with pressure
sensor only)
Current date: month-day
Current date: year
Battery low
Display test
Current time: hours-minutes
Current time: seconds
Primary menu - Single screen view mode
First line: always displays the volume
flowed in m
3
.
Second line: displays the volume flowing
(or instantaneous flow rate) in litres.
To view further data use the magnetically
operated button.
Total operating time
Total non-operating time
Version of main firmware
Version of metrological firmware
Default display
With no flow: volume flowed in
submultiples
With flow: instantaneous flow
Time difference between signal
transmission
Instantaneous flow
Calibration parameters
Transducer signal voltage
Water temperature (in °C)
Display test
Pipe pressure (kPa, version with pressure
sensor only)
Seals
The meter is sealed. It cannot be opened without breaking the seal. Meters must be serviced only by an authorized
centre.
Do not alter or remove the meter's seal. If the seal has been altered or removed the warranty is void.
