Made NADIR - SEARCH and IDENTIFICATION Modes

GU_NADIR_V_3_20_EN 11 / 20
 Menu SEARCH : for quickly locating a cable carrying the transmitter signal :
Press VALID :
• The bar graph continuously indicates the signal level measured in percent
• The signal reading is updated every 2 seconds.
The measurement is instantaneous and in real time.
Press VALID and SCROLL :
 Menu IDENTIFICATION : for a more precise discrimination between cables and phases :
The measurement is made with more sophisticated algorithms in order to better identify the
transmitted signal, and integrated over 5 seconds.
The SEARCH function enables quick location of the cable sought.
The IDENTIFICATION function confirms this for cables and phases with more precision and leaves
the signal level value on the screen together with the highest value in the sequence if the Memo Max
function is activated.
SEARCH
Level xx %
IDENTIFICATION
Level xx %
