GU_NADIR_V_3_20_EN 10 / 20
6 USING NADIR RECEIVER
To start the Receiver : Press ON
The software version number and the telephone number of MADE-SA are shown.
To use with the cable pre-identification Transducer
• Connect this Transducer
• Place the Transducer on the cables, one by one to find the highest signal.
To use with the integral Transducer
• Do not connect a Transducer to the Receiver
• Place the back of the Receiver on the cable and proceed as above.
Menu :
• Press VALID to enter the configuration page: Backlighting ON - OFF
Memo Max ON - OFF
• Memo Max : display the largest signal value in the series of measurements, in
addition to the latest value.
After configuration, press SCROLL.
NADIR V3.00
WWW.MADE-SA.COM
Tel. : +33.494.083.198
MADE SA
CONFIGURATION ←
LIGHTING :
MEMO MAX :
