GU_NADIR_V_3_20_EN 15 / 20
In " PHASE IDENTIFICATION " mode :
• Connect the « MADE-FLEX » (Rogowski coil) Transducer to the Receiver
The Receiver differentiates automatically between Transducers.
Note : Do not put this Transducer around the cable or the screen, only the Phase to be
measured, or only the Neutral of the feeder, depending on the Transmitter connection.
• Close the « MADE-FLEX » coil.
The menus SEARCH or IDENTIFICATION are used as above :
As an indication, the minimum levels observed should be between 30 % and 100 %
(depending on the network and loads). On the "wrong" cables, the signal is < 10 %.
BATTERY CHARGE screen :
Navigation through the MENUS :
• Start the Receiver with : ON
• Press : SCROLL
To change screens, press SCROLL and to enter the screens press VALID.
The little arrow indicates the ACTIVE LINE
.
According to the arrow direction, one can modify the LINE or leave it.
Turn off the NADIR Receiver with the OFF button.
BATTERY CHARGE
100 %
