MADER KM0408312 - Technical Specifications

‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐TECHNICAL DATA‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐
MODEL
KM0408312
Main
Unit
Remote type
Automatic centrifugal clutch;
Spiral bevel gear; Drive shaft
Maximum speed of gear
shaft/engine speed(min
‐1
)
Brush Cutter 7500/9700
Grass trimmer 5800/7500
Idle speed(min
‐1
)3000±150
Vibration values at each handle(m/s
2
)(in accordance with
ISO 22867)
≤15 Measurement Uncertainty:2.1m/s
2
Sound power level Lwa
av(
in accordance with ISO 22868) ≤120 Measurement Uncertainty:3dB
Sound pressure level Lwa
av(
in accordance with ISO 22868) ≤102 Measurement Uncertainty:3dB
Reduction ratio 17:22
Blade rotation direction Counter‐Clockwise(seen from the top)
Type of handle Double grip
Weight when dry(kg) 7.25
Engine
Name of engine 139F
Type
Air‐cooled;4 cycle; vertical piston valve,
gasoline engine
Displacement(mL) 33.5
Maximum output(kW/min
‐1
)0.8/6500
Carburetor Diaphragm‐type
Ignition Transistor magneto
Method of starting Recoil type
Fuel used Gasoline
Fuel tank capacity(L) 0.76
Dry weight(kg) 3.5
Length of main pipe section(mm) 1500
Length of drive shaft section(mm) 1522
Standard blades(mm) KM0408430 Ø255mm 3‐blade(255 x 1.4)
Standard nylon head/nylon rope KM0408520 Ø255mm (nylon)
