MADER KM0408312 - Page 79

Drawing
Drawing
Drawing
Drawing
Part
Part
Part
Part Name
Name
Name
Name
Qty
Qty
Qty
Qty
Drawing
Drawing
Drawing
Drawing
Part
Part
Part
Part Name
Name
Name
Name
Qty
Qty
Qty
Qty
No.
No.
No.
No.
No.
No.
No.
No.
1
Gear case Assy
1
45
Spring
1
2
Stop ring 26
1
46
Bolt M6 x 45
1
3
Stop ring 10
1
47
Wire clamp band
1
4
Bearing 6000 - 2RS/P6
2
48
Harness assy
1
5
Pinion
1
49
Rubber Ring
1
6
Screw M6 x 20
1
50
Handgrip
1
7
Washer 6
1
51
Lock bolt
1
8
Screw M5 x 12
5
52
Cap,upper
1
9
Bolt M6 x 12
1
53
Bracket
1
10
Washer 6
1
54
Spring
1
11
Gear case
1
55
Eddy Seat
1
12
Cover
1
56
Cap,lower
1
13
Bearing 6000/P6
1
57
Bolt M5*16
2
14
Gear
1
58
Box ,left
1
15
Gear Shaft
1
59
Stop button comp.
1
16
Bearing 6000 - 2RS/P6
1
60
Cable comp.
1
17
Stop ring 32
1
61
Bolt M5*30
1
18
Holder A
1
62
Washer 5
1
19
Holder B
1
63
Bolt ST3.5*13
4
20
Washer 10
1
64
Box,Right
1
21
Left Nut
1
65
Handgrip
1
22
Pin 2 x 16
1
66
Spring
1
23
Pipe comp
1
67
Handgrip
1
24
Rubber cover
6
68
Cushion
1
25
Oil - Bearing
6
69
Blade
1
26
Drive shaft
1
70
Nylon Cutter head
1
27
Drive shaft pipe
1
71
Case
1
28
Clutch comp.
1
72
Left Nut A
1
29
Clutch drum comp.
1
73
Washer
1
30
Stop ring 35
1
74
Spring
1
31
Bearing 6202 - 2RZ/P6
1
75
Washer
1
32
Stop ring 15
1
76
Cord
1
33
Cluth Case
1
77
Cord Holder
1
34
Bolt M6 x 20
4
78
Platen
1
35
Washer 6
4
79
Cover
2
36
Washer 6
4
80
Screw M5 x 30
1
37
Stop ring 37
1
81
Bracket
1
38
Hang Ring
1
82
Safety guard
1
39
Hang Handle
1
83
Screw M5 x 16
4
40
Bolt M6 x 16
3
84
Screw ST4.2 x 16
3
41
Ring for limit assy
1
85
Guard
1
42
Nut M6
1
86
Blade
1
43
Washer 6
1
87
Safety guard
1
44
Ring for limit
1
88
Lever Box assy
1
