Maeda MC285C-3 - Page 6

0-4
Item
Page
6.7 SENSORS
2- 108
6.7.1 INCLINATION SENSOR PART NO.: S102M3958000
2- 108
6.7.2 TIP-OVER WARNING DEVICE
2- 108
6.8 LED LAMPS
2- 109
7. MOMENT LIMITER
2- 110
7.1 CONFIGURATION OF MOMENT LIMITER
2- 110
7.2 MONITOR DISPLAY OF MOMENT LIMITER
2- 111
7.3 ML ASSEMBLY
2- 112
7.3.1 LDC CONTROLLER
2- 112
7.3.2 MAIN CONTROLLER TTC60
2- 113
7.3.3 LOWER CONTROLLER TTC36X
2- 114
7.3.4 UPPER CONTROLLER TTC30XH
2- 115
7.3.5 TRI-COLOUR LIGHTS
2- 116
7.3.5.1 TRI-COLOUR LIGHTS MODEL PART NO.: S102M3974000
2- 116
7.3.5.2 TRI-COLOUR LIGHTS CONDITIONS
2- 117
7.3.5.3 MOMENT LIMITER TRI-COLOUR LIGHTS CONDITIONS
2- 117
7.3.5.4 OUTRIGGER NOT INSTALLED WARNING
2- 118
7.3.6 OVERRIDE SWITCH
2- 118
7.4 OR POSITION DETECTION ASSEMBLY
2- 119
7.5 OR OPEN DETECTION ASSEMBLY
2- 120
7.6 OR EXTENSION DETECTION ASSEMBLY
2- 120
7.7 BOOM DISPLACEMENT DETECTION ASSEMBLY
2- 121
7.7.1 TOTAL LENGTH REEL
2- 121
7.7.2 ANGLE DETECTOR
2- 123
7.8 LOAD DETECTION ASSEMBLY
2- 124
7.8.1 PRESSURE AND OIL TEMPERATURE SENSOR
2- 125
7.9 LEVER DETECTION ASSEMBLY
2- 127
7.10 OVER-UNWINDING PREVENTION DEVICE
2- 127
7.11 GROUND DETECTION ASSEMBLY
2- 128
7.12. SLEWING DETECTION ASSEMBLY
2- 129
7.12.1 DIGITAL MAGNETIC REVOLUTION SENSOR PART NO.: S102M395900
2- 129
7.13 OVER-HOISTING PREVENTION DEVICE ASSEMBLY
2- 130
7.14 MOMENT LIMITER OVERVIEW AND MODEL
2- 131
7.14.1 OVERVIEW
2- 131
7.14.2 MODEL
2- 131
7.15 CALIBRATION OF MOMENT LIMITER
2- 131
