16
AIR INTAKE FILTER
The dryer should be cleaned regularly, including the air intake filter. Refer to the Air Intake Filter Assembly chart
when cleaning the filter.
NOTE: Unplug the power cord before cleaning any part of the dryer.
Air Intake Filter Assembly
1
Remove by pulling outwards, holding the upper and lower ends of
the air intake shroud.
NOTE: The air intake filter assembly must be installed when
operating the dryer. The air intake filter assembly must be cleaned
before and after each use.
2
The air intake filter consists of two (2) parts: air intake shroud and
air intake filter.
3
Remove the air intake shroud and take the air intake filter out.
Clean the filter using a soft brush or a vacuum cleaner.
4
Reassemble the air intake filter inside the air intake shroud, then
reinstall the air intake shroud by pushing the housing upwards with
your thumb until the latch is secured to the dryer.
Air Intake Shroud Air Intake Filter
Air Intake Filter
