12
BEFORE EACH USE
1. Make sure the float valve (Figure 4), anti-block shield (Figure 5), and gasket are free of obstruction and
mounted correctly into place.
Disassembly and Assembly of Anti-Block Shield
Disassembly:
Screw upward
counterclockwise.
Assembly:
Screw downward
clockwise.
Anti-Block Shield
2. Before inserting the inner pot to the outer pot, remove debris and water from both.
3. Wipe the outer casing with a soft cloth if it is wet.
4. Install the condensation collector. On the back of the multicooker under the exhaust valve platform, firmly
press the condensation collector in place at the top of the base. This is used to collect excess condensation
from the lid.
Figure 4 Figure 5
Figure 6
Structure Diagram
of Float Valve
Condensation
Collector
To Next Page
