PIEZAS Y FUNCIONES
PARTES DEL PRODUCTO
ACCESORIOS
Figura 2
Figura 3
a� Tapa superior
b� Panel de control
c� Pata ajustable
d� Estructura
e� Gabinete
f Manguera de entrada de agua
g� Manguera de desagüe*
h� Rodillos
i� Cable de electricidad
j� Filtro de la bomba
*
NOTA: Los modelos de 16 pies cúbicos (MCSTCW 16W4 y MCSTCW 16S4) tienen UNA pata de nivelación
ajustable, y la manguera de drenaje está ubicada al costado de la lavadora� Los modelos de 2,0 pies cúbicos
(MCSTCW 20W4 y MCSTCW 20S4) tienen DOS patas de nivelación ajustables, y la manguera de drenaje está
ubicada en la parte posterior de la lavadora�
b d
i
a
g
f
a
e
h j
c
Vista frontal de la lavadora
Vista de la parte posterior de la lavadora
Manguera de suministro de agua (2) Cubierta inferior
Tornillo
Adaptador
de conexión
rápida
Tapa de
entrada
de agua
