31
BIOS
INTEGRATED PERIPHERALS
Integrated Peripherals option changes the values of the chipset registers. These
registers control system options in the computer.
Run the Integrated Peripherals as follows:
1. Choose INTEGRATED PERIPHERALS from the Main Menu and a
screen with a list of options will appear.
2. Use one of the arrow keys to move between options and modify the
selected options by using PgUp/PgDn/+/- keys.
OnChip IDE Channel0 : Enabled
OnChip IDE Channel1 : Enabled
IDE Prefetch Mode : Enabled
Primary Master PIO : Auto
Primary Slave PIO : Auto
Secondary Master PIO : Auto
Secondary Slave PIO : Auto
Primary Master UDMA : Auto
Primary Slave UDMA : Auto
Secondary Master UDMA : Auto
Secondary Slave UDMA : Auto
Init Display First : PCI Slot
KBC input clock : 8 MHz
Onboard FDC Controller : Enabled
Onboard Serial Port 1 : 3F8/IRQ4
Onboard Serial Port 2 : 2F8/IRQ3
UART Mode Select : IrDA
UART2 Duplex Mode : Half
RxD, TxD Active : Lo, Lo
IR Transmission Delay : Disabled
Onboard Parallel Port : 378/IRQ7
Parallel Port Mode : ECP + EPP
ECP Mode Use DMA : 3
EPP Mode Select : EPP1.7
Power On Function :
KB Power On Password : Enter
Hot Key Power On : Ctrl - F1
ROM PCI/ISA BIOS (2A6LGSNE)
INTEGRATED PERPHERALS
AWARD SOFTWARE, INC.
ESC : Quit
F1 : Help
F5 : Old Value
F7 : Load Setup Defaults
: Select Item
PU/PD/+/- : Modify
(Shift)F2 : Color
To Next Page
