BIOS

Choose the printer I/O address: 378H/IRQ7 (default), 3BCH/

IRQ7, 278H/IRQ5 or Disabled.

Onboard Paralle Port

Choose Normal (default), ECP/EPP, SPP mode. The mode

depends on the external device connected to this port.

Parallel Port Mode

Choose Half (default) or Full.

UART2 Duplex Mode

Enabled: Enable delay when transferring data.

Disabled (default): Disable delay when transferring data.

IR Transmission Delay

Choose Standard (default), HPSIR or ASKIR.

UART Mode Select

Choose DMA3 (default) or DMA1. Most sound cards use

DMA1. Check with your sound card configuration to make

sure that there is no conflict with this function.

ECP Mode Use DMA

Note: The above 2 options will not be displayed unless the

EPP/ECP is selected.

Choose EPP1.7 (default) or EPP1.9. EPP1.9 supports hard-

ware handshake. This setting is dependent upon your EPP

device.

EPP Mode Select

Choose Lo,Lo (default) / Lo,Hi / Hi,Hi / Hi,Lo.

RxD, TxD Active

Note: The above 2 options wont work unless UART2 Mode

HPSIR/ASKIR is selected.
